Temperature Sensor TE2





Main features



   Compact and light weight



   „„Available with 4...20 mA transmitter or Pt100 output

   Available with hygienic as well as industrial process connections

   „„Programmable by FlexProgrammer 9701







Applications



   Food & Beverage



   „Laboratory & Medical



   „Oil & Gas / Chemical



    „Water & Waste water



   Energy



   „Transportation & Logistics





Technical specification



Housing

Compact Ø 18mm

Stainless steel AISI 304 (1.4301)

El. connection

M12 or DIN 43650 plug

Output

Pt100 or 4...20mA

Sensor tube material

Stainless steel AISI 316L (1.4404)

PEEK

Sensor diameter outside

Ø 6mm

Sensor length

< 3 000 mm

Standard response tip

Fast response tip

Ø 6, Ø 4 or Ø 3



资料:

TE2_EN_201401.pdf
